| Eyepiece | Standard | Auxiliary Lens 0.5X | Auxiliary Lens 1.5X | Auxiliary Lens 2X |
| W.D. 105mm | W.D. 177mm | W.D. 47mm | W.D. 26mm |
| Mag. | F.O.V | Mag. | F.O.V | Mag. | F.O.V | Mag. | F.O.V |
| 10X/22mm | 6.7X | 32.8mm | 3.4X | 65.7mm | 10.1X | 21.9mm | 13.4X | 16.4mm |
| 45.0X | 4.9mm | 22.5X | 9.8mm | 67.5X | 3.3mm | 90.0X | 2.4mm |
| 15X/16mm | 10.1X | 23.9mm | 5.0X | 47.8mm | 15.1X | 15.9mm | 20.1X | 11.9mm |
| 67.5X | 3.6mm | 33.8X | 7.1mm | 101.3X | 2.4mm | 135.0X | 1.8mm |
| 20X/12mm | 13.4X | 17.9mm | 6.7X | 38.5mm | 20.1X | 11.9mm | 26.8X | 9.0mm |
| 90.0X | 2.7mm | 45.0X | 5.3mm | 135.0X | 1.8mm | 180.0X | 1.3mm |
| 25X/9mm | 16.8X | 13.4mm | 8.4X | 26.9mm | 25.1X | 9.0mm | 33.5X | 6.7mm |
| 112.5X | 2.0mm | 56.3X | 4.0mm | 168.8X | 1.3mm | 225.0X | 1.0mm |
| 30X/8mm | 20.1X | 11.9mm | 10.1X | 23.8mm | 30.2X | 7.9mm | 40.2X | 6.0mm |
| 135.0X | 1.8mm | 67.5X | 3.6mm | 202.5X | 1.2mm | 270.0X | 0.9mm |
| Magnification | 6.7X-45X, 3.4X-270X with optional eyepieces and objectives |
| Eyepiece | WF10X/22mm high-eyepoint, wide-field; Convenient for observers wearing glasses |
| Optional Eyepiece | WF10X/22mm, WF15X/16mm, WF20X/12mm, WF25X/9mm, WF30X/8mm |
| Main Body | Binocular head, 45° inclined, 360° rotatable, can be locked in any position desired |
| Interpupillary Distance adjustment:54-75mm; Diopter adjustment:±5 diopters |
| Objective | 0.67X-4.5X stereo zoom; Zoom Ratio:6.7:1 |
| Aux Lens | 0.3X, 0.5X, 0.7X, 0.75X, 1.5X, 2X |
| Focusing Mount | A1 focusing mount with vertical working distance 50mm |
| Illumination | Double gooseneck LED illumination with independent switches and adjustable intensity |
